EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Troubleshooting CONFIDENTIAL
SEIKO EPSON 28 Revision C
CIRCUIT BOARDS
Figure 2-6.
SW Board (p67)
RS Board
(EB-S11/X11 only) (p.79)
MA Board / RS Board
(EB-S11/X11 only) (p79)
