Epson EH-TW9000W Service Manual

EH-TW8000/TW9000/TW9000W Appendix CONFIDENTIAL
SEIKO EPSON 123 Revision A
 3rd page
The error log of the projector is displayed.
• The last 5 error logs are displayed (the latest on top). None is displayed if there’s no
error.
• In the case of the display in the previous page, the latest error is “Internal Overheat”.
When error occurred, Total Operation Time was 9 hours 46 minutes 57 seconds, Lamp
Operation Time was 5 hours 36 minutes 27 seconds, the time after the lamp turned ON
was 0 hours 2 minutes 23 seconds, the projector’s status was “Lamp ON”.
• The 2nd latest error is “Fan Error”. When error occurred, Total Operation Time was 8
hours 35 seconds 34 minutes, Lamp Operation Time was 5 hours 34 minutes 4 seconds,
the time after the lamp turned ON was 0 hours 0 minutes 1 second, the projector’s status
was “Warming up”.
No. Description
1 Error log items. see Table 4-1 “Error log items”
2 Last 5 error logs are displayed. #2 (top) is the latest.
3 Error count
4 Control Data 1
5 Control Data 2
CD TOT (h:m:s) LOT (h:m:s) POT (h:m:s) ST
CD TOT (h:m:s) LOT (h:m:s) POT (h:m:s) ST
Error
Error
: TH
: TH
00009 4657 00005 3627 00000 0223 01
00009 4657 00005 3627 00000 0223 01
Log
Log
: FN
: FN
00008 3534 00005 3404 00000 0001 02
00008 3534 00005 3404 00000 0001 02
00008 4246 00005 0516 00000 1441 01
00008 4246 00005 0516 00000 1441 01
: LF
: LF
00007 3451 00004 4221 00000 0000 02
00007 3451 00004 4221 00000 0000 02
: LF
: LF
: LF
: LF
00007 3451 00004 4221 00000 0000 02
00007 3451 00004 4221 00000 0000 02
Error
Error
: TH01 FN01 SE00 LE00 LF03 RA00 RO00 II00
: TH01 FN01 SE00 LE00 LF
03
RA00 RO00 II00
Count
Count
:
WL00 WS00
WL00 WS00
PB00 IV00 SH00 FE00 FP00
PB00 IV00 SH00 FE00 FP00
: ID00 LC00 EC00 CF00
: ID00 LC00 EC00 CF00
AI00 RS00 RP00 DU00
AI00 RS00 RP00 DU00
Control
Control :
3F5324FF
3F5324FF
AF3C27B34B0EF3 0F
AF3C27B34B0EF3 0F
VE 00
VE 00
(2)
(3)
(4)
(5)
(1)
Table 4-1. Error log items
Item Contents Representation
Error Log
CD Error Code Two alphabets
TOT Total Operation Time
h: 5-digit number (00000-
65535)
Over 65535: “65535” (Not
cleared to “0.”)
m: 2-digit number (00-59)
s: 2-digit number (00-59)
LOT Lamp Operation Time
POT Time after Lamp is ON
ST PJ (Projector)’s status
Acquired data of PWR? of the
ESC/VP21 command
