Basic Operations
29
Caution
When transporting the projector, return the horizontal lens position to the central position and the vertical
lens position to the bottom position. If you transport the projector when the lens is shifted up, down, left,
or right, the lens shift mechanism could be damaged. Also, attach the protective pad that was attached
when you purchased it.
c
If keystone distortion occurs when projecting at an angle by using lens shift, you may not be able
to correct the distortion completely. When using lens shift, setup the projector so that it is parallel
to the screen, and then only use lens shift to adjust the position.
Correcting Keystone Distortion
You can use the buttons on the control panel to correct keystone distortion.
Open the control panel cover at the side to operate the control panel.
s
p.9
Press the
or buttons to display the adjustment gauges.
When the gauges are displayed, press the
and buttons to perform vertical correction.
When the top or bottom is too wide
c
•
The projected screen becomes smaller when correcting keystone distortion. Increase the projection
distance to fit the projected screen to the screen size.
•
You can make keystone settings from the Configuration menu. s Settings - Keystone p.70
•
You can make effective corrections within a projection angle of 30° top to bottom.
•
For position adjustment, you can maintain the quality of the projected image by performing correction
using lens shift. Use keystone when you cannot make adjustments using lens shift.
Hiding the Image Temporarily
You can use this to temporarily hide the image on the screen.
Press the
button to show or hide the image.
c
For movies, because the movie continues to play even when it is hidden, you cannot return to the
point at which you hid the image using the
button.
