Epson EH-TW9200 User Manual

Contents
4
Skin Tone ............................36
Detailed Image Adjustments . . . . . . . . . . 37
Adjusting the Sharpness .................. 37
Setting Auto Iris ........................ 38
Frame Interpolation (EH-TW9200W/EH-
TW9200/EH-TW8200W/EH-TW8200 only) ...... 38
Super-resolution .......................39
Panel Alignment ....................... 39
Image Processing ....................... 40
Selecting the Color Gamut (EH-TW9200W/EH-
TW9200 Only) ......................... 41
Viewing the Image at the Saved Image
Quality (Memory Function) . . . . . . . . . . . 42
Saving Function ........................ 42
Saving a Memory ....................... 42
Loading a Memory ...................... 43
Deleting a Saved Memory ................. 43
Renaming a Memory .................... 43
Useful Functions
Enjoying 3D Images .................. 45
Setting 3D Images ...................... 45
When the projector detects a 3D format . . . . 45
When the projector cannot detect a 3D
format ............................. 45
If the 3D image cannot be viewed .........45
Using 3D Glasses ....................... 46
Charging the 3D Glasses ................46
Pairing 3D Glasses ....................46
Wearing the 3D Glasses ................47
Range for Viewing 3D Images .............. 47
Warnings Regarding Viewing 3D Images......48
Converting 2D Images to 3D and Viewing.....50
Connecting with WirelessHD (EH-
TW9200W/EH-TW8200W Only) . . . . . . . . 52
Installing the WirelessHD Transmitter........52
WirelessHD Transmitter part names ........ 52
Setting the WirelessHD Transmitter ........ 53
Projecting Images ...................... 54
WirelessHD Settings Menu................56
WirelessHD Transmission Range ............ 56
Useful Functions of the WirelessHD Transmitter
....................................57
Switching the target image .............. 58
Switching the image source .............59
Remote control operating range .......... 60
Using the HDMI Link Function ........ 61
HDMI Link Function ..................... 61
HDMI Link Settings ...................... 61
Device Connections ..................... 62
Projecting Two Different Images Using
Picture in Picture .................... 63
Types of Screen that can be Displayed
Simultaneously ........................ 63
Projecting on a Picture in Picture ............ 63
Starting Picture in Picture ............... 63
Changing the Picture in Picture settings . . . . 64
Configuration Menu
Configuration Menu Functions ........ 65
Configuration Menu Operations............65
Configuration Menu Table ................66
Image menu........................66
Signal menu ........................ 68
Settings menu ....................... 70
Extended menu ...................... 73
Memory menu ....................... 75
Info menu .......................... 75
Reset menu ......................... 75
Picture in Picture menu................76
Troubleshooting
Problem Solving . .................... 77
Reading the Indicators ................... 77
Indicator status during an error/warning....77
Indicator status during normal operation . . . . 79
When the Indicators Provide No Help........80
Check the problem .................... 80
Problems relating to images .............80
Problems when projection starts ..........85
Problems with the remote control ......... 85

Epson EH-TW9200 Specifications

Display

projection system	3LCD Technology, RGB liquid crystal shutter
resolution	Full HD 1080p, 1920 x 1080, 16:9
color light output	2, 400 lumen
white light output	2, 400 lumen
contrast ratio	600, 000 : 1

Optical

projection ratio	1.34 - 2.87:1
zoom factor	1 - 2.1
projection size	30 inches - 300 inches
projection distance wide	0.9 m - 9 m (100 inch screen)
projection distance tele	1.9 m - 19.2 m (100 inch screen)
focal distance	22.5 mm - 47.2 mm

Power and Energy

lamp power	230 W, 176 W (economy mode)
energy use	334 W, 270 W (economy)
lamp durability	4, 000 h, 5, 000 h (economy mode)

Weight and Dimensions

product dimensions	466 x 140 x 395 mm (Width x Depth x Height)
product weight	8.4 kg
carton dimensions	575 x 510 x 350 mm
