16
1
2
Remove the cover when the projector has sufficiently cooled
down. It takes about one hour after the power is turned off for the
lamp to become sufficiently cool.
Replacing the Lamp
User's Guide "Replacing the Lamp"
Use the screwdriver that is supplied with the spare lamp or your own cross head screwdriver.
How to replace the lamp
Disconnect the
power cable.
Remove the lamp
cover at the side of
the projector.
Loosen the lamp cover fixing screw.
Loosen the two lamp
fixing screws.
Slide the lamp cover straight out, and then lift it up to
remove it.
Hold the knob and
pull out the old lamp.
1
2
3
A beep will sound and the Power indicator will switch to flashing green.
User's Guide "Turning the Projector On"
Projector Preparation and Adjustments
Connect the power
cable to the
projector and to an
electrical outlet.
Press .
When "Direct Power ON" is set
to "ON", the power will turn on
when the power cable is
connected, without the need to
press .
User's Guide
"List of Configuration Menu
Commands"
Simple!
Place your fingers against the
[
]
and
[
]
on the lens cover
and press in while pulling the lens cover forward to remove it.
To use the remote control, set the
[R/C] switch to "ON".
Power indicator
Flashing green (warm-up in progress/approx. 30 seconds)
→ Lit green
User's Guide "Preventing Theft (Password Protect)"
will not work while warm-up is in progress.
If Password Protect has been enabled, the password entry
screen will be displayed. Enter the password.
404401202 BK
2-B Rev.2
404401202 DIC188
2-B Rev.2
