11
Part Names and Functions
Base
• Air filter (air intake vent)
sp.59, p.65
This prevents dust and other foreign particles
from getting inside the projector when air is
drawn in. It should be cleaned and replaced
periodically.
• Ceiling mount holes (3 points) sp.58, p.75
Attach the optional ceiling mount here when suspending the projector from a ceiling.
• Front adjustable foot
• Lens cover string attachment
ring
Remove this when suspending the projector
from a ceiling.
• Foot adjust lever
(See the Quick Setup sheet)
To Next Page
