Epson Expression 10000XL Setup Guide

Setting Up the Scanner 13
English
Setting Up
You must install the software BEFORE connecting the scanner
to your computer.
1. Make sure that the scanner is turned off. The scanner is off
when the . Power button is raised.
2. Connect the power cord to the AC inlet on the back of the
scanner, and then plug the other end into an electrical outlet.
Note:
When you connect the power cord to the AC inlet, you need to force
it in at the entrance; otherwise, the transportation lock will not be
released.
. Power button

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
