Epson Expression 10000XL Setup Guide

Options 21
English
6
Options
Using the Transparency Unit
The optional A3 Transparency Unit (B81336✽ ) makes it possible
to scan films and slides, in full color. Once you install the
Transparency Unit, you can leave it in place even when you want
to return to scanning reflective (paper) documents.
Unpacking the Transparency Unit
Make sure that all the items shown below are included and have
not been damaged during shipping. Contact your Epson dealer if
any item is missing or damaged.
Transparency Unit
film holders
transparency guide

Epson Expression 10000XL Specifications

Resolution

optical resolution	2400 dpi
maximum resolution with Micro Step Drive technology	2400 x 4800 dpi
interpolated resolution	12, 800 x 12, 800 dpi

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without optional unit	45W
power consumption operating with optional unit	55W
power consumption sleep mode without optional unit	6W

Operating Environment

operating temperature	41ºF to 95ºF (5ºC to 35ºC)
operating humidity	10% to 80% (no condensation)
storage humidity	10% to 85% (no condensation)

Interface and Connectivity

interface	USB 1.1/2.0, IEEE 1394 (FireWire), optional Ethernet
system compatibility	Windows 98SE, 2000 Me, XP; Macintosh OS 9.1 or later

Weight and Dimensions

maximum scan area	12.2" x 17.2" (310mm x 437mm)
width	25.8" (656mm)
depth	18.0" (458mm)
height	6.2" (158mm)
weight	28.7 lb (13 kg approx.)
