WARNING: High
voltage
is present inside the printer when
the power is on. Do not attempt to remove the upper case
unless the is turned off and the power cord is
unplugged. Also, do not touch contacts on the printer’s
circuit because many of the components be
destroyed by static electricity built up in your body.
2. Remove the printer cover, paper guide, ribbon cartridge, and any
installed options.
3. Remove the platen knob and push the paper release lever back to the
single sheet position.
4. Remove the screw located inside the front center of the upper case.
7-24
Using Printer Options
