4. Slide the left sprocket approximately 12 mm (0.5 inch) from the far left position and push the lever
back to lock it in place. Then slide the right sprocket to match the width of your paper, but do not
lock it.
* approx. 12 mm (0.5 inch)
5. Make sure your paper has a clean, straight edge. Then open the sprocket covers.
Note:
Make sure the printer is off before you insert the paper in the paper slot. If you insert the paper while it
is on, a paper jam may occur.
6. Insert the paper into the rear, front, or bottom paper slot as shown in the illustration below until it
emerges between the platen and the ribbon guide. Then pull up the paper until the perforation
between the first and second pages is even with the top of the printer’s ribbon.
Rear slot:
Load paper in the rear slot with the printable side facing up.
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Paper Handling 35
