10. Pause button
❏ Stops printing temporarily, and resumes printing when pressed again.
❏ Press and hold for three seconds to enter Micro Adjust mode. Press again to exit Micro Adjust
mode.
11. Paper Out light
❏ On when no paper is loaded in the selected paper source or paper is not loaded correctly.
❏ Flashes when paper has not been fully ejected or a paper jam has occurred.
12. Tear Off/Bin lights
❏ Both of the two lights flash when continuous paper is in the tear-off position, and both of the lights
are off when continuous paper is not in the tear-off position.
❏ The left light is on when Card mode is selected.
❏ Both the lights are off when bin 1 of the optional cut-sheet feeder is selected.
❏ The right light is on when bin 2 of the optional cut-sheet feeder is selected.
13. Pitch lights
Indicate which pitch is selected.
14. Font lights
Indicate which font is selected.
Selecting a Font and Pitch
You can select one of the printer’s five fonts and pitch by using the buttons on the printer’s control
panel, as described below.
Note:
❏ Settings you make in application programs usually override settings you make from the printer’s
control panel. For best results, use your application to select a font and make other settings.
❏ The available pitch depends on the font you select. See the table below for more information.
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Control Panel 90

Epson FX-2190II Specifications

General

Color	No
Bitmap fonts	Roman, Sans Serif
Character pitch	10, 12, 15, 17, 20 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum print speed (LQ)	115 cps
Page description languages	ESC P, OKI ML, PPDS
Maximum print speed (draft)	463 cps
Maximum printing width (columns)	-
Number of pins	9
Sustainability certificates	ENERGY STAR
Print direction	Bi-directional
Mean time between failures (MTBF)	25000 h
Certification	UL62368-1, CAN/CSA C22.2 No. 60950-1, IEC/EN62368-1 EMI: FCC 15 B A, ICES-003 A, EN55032 (CISPR pu.32) A, As/NZS CISPR32 A CE: EN62368-1, EN55032 A, EN61000-3-2, EN61000-3-3, E55024
Product color	Black
Sound pressure level (printing)	55 dB
Paper feed	Pull tractor, Push tractor
Cut sheet width range	182.88 - 419.1 mm
Cut sheet length range	256.54 - 355.6 mm
Paper tray media types	Envelopes
Continuous paper width range	101.6 - 406.4 mm
Continuous paper length range	101.6 - 558.8 mm
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Standard interfaces	Parallel
Optional connectivity	Ethernet, USB 2.0
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Power consumption (standby)	12 W
Power consumption (typical)	57 W

Weight and Dimensions

Depth	375.92 mm
Width	612.14 mm
Height	175.26 mm
