Epson FX-2190II User Manual

For Windows 8, 8.1:
Click Desktop on the Start screen, move the cursor to the top-right corner of the screen. Click
Settings, and then click Control Panel. Next, click View devices and printers from the
Hardware and Sound category.
For Windows 7:
Click Start, and then click View devices and printers.
For Windows XP:
Click Start, and click Printers and Faxes.
For Windows XP Home Edition:
Click Start, click Control Panel, then click Printers and Faxes.
For Windows Vista:
Click Start, click Control Panel, click Hardware and Sound, and then click Printers.
2. For Windows 10, 8, 8.1, or 7:
Right-click your printer icon, click Printer properties, and then click the Sharing tab in the
appearing screen.
For Windows Vista or XP:
Right-click your printer icon, and click Sharing in the menu that appears.
For Windows XP, if the following menu appears, click either Network Setup Wizard or If you
understand the security risks but want to share printers without running the wizard,
click here.
In either case, follow the on-screen instructions.
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Printer Software 77

Epson FX-2190II Specifications

General

Color	No
Bitmap fonts	Roman, Sans Serif
Character pitch	10, 12, 15, 17, 20 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum print speed (LQ)	115 cps
Page description languages	ESC P, OKI ML, PPDS
Maximum print speed (draft)	463 cps
Maximum printing width (columns)	-
Number of pins	9
Sustainability certificates	ENERGY STAR
Print direction	Bi-directional
Mean time between failures (MTBF)	25000 h
Certification	UL62368-1, CAN/CSA C22.2 No. 60950-1, IEC/EN62368-1 EMI: FCC 15 B A, ICES-003 A, EN55032 (CISPR pu.32) A, As/NZS CISPR32 A CE: EN62368-1, EN55032 A, EN61000-3-2, EN61000-3-3, E55024
Product color	Black
Sound pressure level (printing)	55 dB
Paper feed	Pull tractor, Push tractor
Cut sheet width range	182.88 - 419.1 mm
Cut sheet length range	256.54 - 355.6 mm
Paper tray media types	Envelopes
Continuous paper width range	101.6 - 406.4 mm
Continuous paper length range	101.6 - 558.8 mm
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Standard interfaces	Parallel
Optional connectivity	Ethernet, USB 2.0
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Power consumption (standby)	12 W
Power consumption (typical)	57 W

Weight and Dimensions

Depth	375.92 mm
Width	612.14 mm
Height	175.26 mm
