EPSON LQ-300+ Revision C
Appendix Parts List 88
516 PULLEY ASSY.,DRIVEN
517 HARNESS,HP
518 C.P.B SCREW
519 MOTOR ASSY.,PF
520 PAPER GUIDE
521 DETECTOR,PE,REAR
522 HARNESS,PE,REAR
523 DETECTOR,PE,BOTTOM
524 HARNESS,PE,BOTTOM
525 HOLDER,ROLLER,PF
526 ROLLER,PF,DRIVEN
527 ROLLER,PF,DRIVE,REAR;B
528 COMPRESSION SPRING,13.72
529 SHAFT,RELEASE
531 RETAINING RING
532 BUSHING,11
533 U-TYPE,11.2X0.13X16S/NA
534 PLAIN WASHER
535 PLATEN
536 CARRIAGE ASSEMBLY
538 OIL PAD
539 LEVER,G,ADJUST
540 RIBBON MASK
541 TIMING BELT
542 BUSHING,PARALLEL,ADJUST
Table 7-14. LQ-300+ Parts List
Code Part Name
544 HARNESS,PG
545 PAPER GUIDE,LOWER
546 CABLE,HEAD,FRONT
547 CABLE,HEAD,REAR
559 DAMPER
560 FRAME,BASE
561 PAPER GUIDE,SUPPORT
562 GROUNDING PALTE,SHAFT,CR
563 SHEET,CABLE,HEAD
564 GEAR,34
565 SPUR GEAR,27.5
566 PLAIN WASHER
567 COMPRESSION SPRING,1.18
569 HARNESS,RELEASE
570 PAPER EJECT ASSY.
571 COMBINATION GEAR,17.5,27
573 GROUNDING PLATE,CS
575 GROUNDING WIRE,RIGHT
576 GROUNDING PLATE,PF
577 SHEET,PROTECT,CABLE
578 SHEET,PROTECT,M/B
579 LEAF SPRING,8.6X0.13X15,S/NA
580 C.B.P-TITE,3X10,F/ZN
581 C.B.S. SCREW
582 P.W.,8.4X0.1X15,S/NA
Table 7-14. LQ-300+ Parts List
Code Part Name
