Epson LQ-300+ - Color upgrade kit

2-42
Using the Printer
Color upgrade kit
The optional color upgrade kit (C83211✽) includes a color ribbon
cartridge and a motor unit.
Follow these steps to install the kit:
1. Turn off the printer and remove the printer cover and paper
tension unit. Slide the connector cover on the printer and pull
it out as shown below.
