Epson LX-300 User Manual

12. Attach the paper guide to the cut-sheet feeder as shown below.
13. Open the printer cover. Place the printout guide in the middle.
Close the printer cover.
14. Slide the left edge guide to the center until it stops at the guide
mark. Then slide the right edge guide to the opposite guide mark.
View from above
Release tab
Release tab
BB2-19
BB2-19a
R
Blueberry REV.F
A5 size Chapter 2
95/05/25
Using the Printer
2-27

Epson LX-300 Specifications

General

Print Method	9-pin impact dot matrix
Interface	Parallel
Paper Handling	Friction feed, tractor feed
Weight	4.4 kg
Operating Environment	Temperature: 5 - 35°C, Humidity: 10 - 80%
