Chapter 7 Options and Consumables 139
2. Place the base plate on the stand and fasten the two together
with the plastic spacing clips. Make sure you orient the stand
and base plate as shown below.
3. Hook the tension lever onto both ends of the stand as shown
below. While pulling up on the tension lever, fit the wire ends
of the tension lever into the holes in the stand. The roll paper
holder is assembled.
Installing the roll paper holder
Follow these steps to install the roll paper holder on your printer:
1. Make sure the printer is turned off.
