Epson PLQ-20 User Manual

Chapter 1 Setting up the Printer 18
For DOS programs
To control the printer from DOS application programs, you need
to select the printer you are using.
If the list in your application does not include your printer, choose
the first available printer from the list below.
Choose the Epson printer at the appropriate step in the
installation or setup procedure. If the list in your application does
not include your printer, choose the first available printer from
the list below:
Note:
The printer on this list are also available for PLQ-20M printers.
Once the printer software has been successfully installed onto
your computer, your printer is ready to use.
PLQ-20 LQ-510/550/1010
LQ-2090 LQ-200
LQ-2080/2180 LQ-500
LQ-2070/2170 LQ-860+/1060+
LQ-1070/1070+ LQ-2550
LQ-870/1170 LQ-2500
LQ-850+/1050+ LQ-800/1000
LQ-850/1050 LQ-1500

Epson PLQ-20 Specifications

General

Color	Yes
Character sets	ISO 8859-15, PC437, PC850, PC858
Character pitch	10, 12 cpi
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, Industrial 2/5, Interleaved 2/5, UPC-A, UPC-E
Maximum number of copies	7 copies
Maximum print speed (LQ)	144 cps
Maximum print speed (draft)	432 cps
Maximum printing width (columns)	94
Needles	24
Fonts included	PR2: 4LQ & 2 Draft Bitmap, 8 Barcode, ESC/P: 9LQ & 1 Draft Bitmap, 4 Scalable typefaces, 8 Barcode
Print technology	Dot matrix
Connectivity technology	Wired
Print direction	Bi-directional
Ribbon life (black, LQ)	5 million characters
Ribbon life (black, draft)	10 million characters
Mean time between failures (MTBF)	10000 h
Standard interfaces	Parallel, RS-232, USB 2.0
Certification	73/23 EEC, EN60950, EN55022 (CISPR pub.22) class B, AS/NZS 3548 class B, EN55022 class B, EN61000-3-2, EN61000-3-3, EN55024
Product color	Gray
Country of origin	Indonesia
Page description languages	Epson ESC/P2, PPDS
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8 W
Power consumption (typical)	60 W
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Paper tray media types	Envelopes
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2040 mm
Quantity per pallet	28 pc(s)
Quantity per pallet (UK)	42 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	6 pc(s)
Package depth	460 mm
Package width	380 mm
Package height	270 mm
Package weight	9060 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	280 mm
Width	384 mm
Height	203 mm
