Appendix A Product Information 156
Environmental
Paper
For information about available paper types and their printable
area, refer to the Paper Specification, which is included on the User
CD-ROM.
Magnetic stripe reader/writer (horizontally
installed only)
The horizontal magnetic stripe reader/writer is used to read and
write data on the magnetic stripe on bank passbooks. See the
following specifications of this device for details.
Temperature Humidity
(without
condensation)
Operation (passbook,
plain paper, recycled
paper,and multipart
forms)
5to35°C (41 to 95°F) 10 to 80% RH
Operation (roll paper)15to25°C (59 to 77°F) 30 to 60% RH
Storage -30 to 60°C(-22to
140°F)
0 to 85% RH
Recording code BCD Binary Coded decimal, 4
data bits,
1 VRC parity control bit
Recordable characters column 3 of the ASCII table
Recordable formats IBM3604, DIN/ISO, ISO7811,
IBM4746, ANSI, HT-2751-CIZ,
ISO8484
