212
Setting Options Description
Image Shift Varying positions available Adjusts the position of the
projected image
Connect ELPCB02 On
Off
Set to On to switch the input
source between the HDMI2 port
and HDMI3 port each time you
press the HDMI2 button on the
optional interface box
Remote Receiver Front/Rear
Front
Rear
Off
Limits reception of remote control
signals by the selected receiver;
Off turns off all receivers
Screen Type 4:3
16:6
16:9
16:10
21:9
Sets the aspect ratio to fit the
image on the projection surface
(setting only displayed when
Content Playback is Off)
Screen Position Varying positions available Shifts the image position on the
screen
High Altitude Mode On
Off
Regulates the projector's
operating temperature at
altitudes above 4921 feet (1500
m)
Source — Displays settings saved for each
input source
Blanking Top
Bottom
Left
Right
Hides an area of the projected
image that you select (setting
only displayed when Content
Playback is Off)
To Next Page
