After correction, your image is slightly smaller.
Note: If the projector is installed out of reach, you can also correct the image shape using the
Keystone settings in the projector menus.
Parent topic: Image Shape
Related references
Projector Feature Settings - Settings Menu
Correcting Image Shape with Quick Corner
You can use the projector's Quick Corner setting to correct the shape and size of an image that is
unevenly rectangular on all sides.
1. Turn on the projector and display an image.
Note: You can display a pattern to aid in adjusting the projected image using the Settings menu.
2. Press the Menu button.
3. Select the Settings menu and press Enter.
4. Select the Keystone setting and press Enter.
5. Select the Quick Corner setting and press Enter. Then press Enter again.
You see the Quick Corner adjustment screen.
57

Epson PowerLite W16 Specifications

Display

pixel number	1, 024, 000 dots (1280 x 800) x 3
color brightness	3000 lumens in 2D mode
white brightness	3000 lumens in 2D mode
aspect ratio	Native 16:10 widescreen, supports 16:9/4:3
native resolution	1280 x 800 (WXGA)

Lamp

lamp type	200 W UHE (E-TORL)
lamp life (ECO mode)	Up to 5000 hours
lamp life (normal mode)	Up to 4000 hours

Projection

throw ratio range	1.30 – 1.56
size (projected distance)	33" – 318"
keystone correction (automatic)	Vertical: ± 30 degrees, Horizontal: ± 20 degrees

Power

power supply voltage	100 – 240 V AC, ±10%, 50/60 Hz
power consumption (ECO mode)	237 W
power consumption (normal mode)	289 W

Dimensions and Weight

dimensions including feet	12.8" x 9.6" x 3.1"
dimensions excluding feet	12.8" x 9.6" x 3.0"
weight	6.0 lb
