Epson PowerLite W16 User Manual

To change settings for an input source, make sure the source is connected and select that source.
Setting Options Description
Color Mode See the list of available Color Adjusts the vividness of image
Modes colors for various image types
and environments
Brightness Varying levels available Lightens or darkens the overall
Contrast Varying levels available Adjusts the difference between
light and dark areas of the image
Color Saturation Varying levels available Adjusts the intensity of the image
colors
Tint Varying levels available Adjusts the balance of green to
magenta tones in the image
Sharpness Varying levels available Adjusts the sharpness or
softness of image details
Color Temp. (color temperature) High Sets the overall color tone; High
tints the image blue and Low
Medium
tints the image red
Low
89

Epson PowerLite W16 Specifications

Display

pixel number	1, 024, 000 dots (1280 x 800) x 3
color brightness	3000 lumens in 2D mode
white brightness	3000 lumens in 2D mode
aspect ratio	Native 16:10 widescreen, supports 16:9/4:3
native resolution	1280 x 800 (WXGA)

Lamp

lamp type	200 W UHE (E-TORL)
lamp life (ECO mode)	Up to 5000 hours
lamp life (normal mode)	Up to 4000 hours

Projection

throw ratio range	1.30 – 1.56
size (projected distance)	33" – 318"
keystone correction (automatic)	Vertical: ± 30 degrees, Horizontal: ± 20 degrees

Power

power supply voltage	100 – 240 V AC, ±10%, 50/60 Hz
power consumption (ECO mode)	237 W
power consumption (normal mode)	289 W

Dimensions and Weight

dimensions including feet	12.8" x 9.6" x 3.1"
dimensions excluding feet	12.8" x 9.6" x 3.0"
weight	6.0 lb
