Epson SC-T3100M Series User Manual

Settings item Settings value Explanation
Page Margin
3 mm
*
Select the top, bottom, left, and right margin values.
For a cut sheet, the top, bottom, left, and right margin values are 3
mm regardless of the settings.
5 mm
Smoothing On
This setting is enabled when Resolution is set to Standard and
there is no resolution specification in the sent print data. Setting
this to On will print at the maximum resolution corresponding to
the Paper Type setting for the paper selected in Paper Source, but
depending on the data, this may result in a long print time, or
failures in printing because of insufficient memory.
Off
*
Base Output Size
Auto
*
The hard clip area of the PS command of the data becomes the
base output size. The actual output size depends on the Page
Margins option. When the data does not contain a PS command,
the smallest rectangle area
of in the following illustration
including the print object becomes the base output size.
A Series
The compatible standard sizes for the selected Paper Source are
displayed, therefore select the Base Output Size. The actual output
size depends on the Page Margins option.
For a cut sheet, this setting is available only when the data does
not contain a PS command. If the data contains a PS command, this
setting is not available, and the hard clip area of the PS command
becomes the Base Output Size.
US-ANSI
US-ARCH
B Series (ISO)
B Series (JIS)
Others
User-Defined Select this option when outputting at non-standard sizes. After
selecting this setting, set Paper Width and Paper Height. You can
set in 0.1 mm increments.
The actual output size depends on the Page Margins option.
SC-T3100M Series/SC-T5100 Series/SC-T3100 Series/SC-T5100N Series/SC-T3100N Series/SC-T2100 Series User's Guide
Using the Menu
145
