c
Important:
❏ We recommend that you remove and shake
the installed ink cartridges thoroughly once
every three months to ensure print quality.
❏ The ink freezes if left at below -20°C for a long
time. If it does freeze, leave it at room
temperature (25°C) for at least four hours
(without condensation).
❏ Do not refill the ink.
MFP Scanner specifications
Read width
153 to 914.4 mm (36 inches)
*
Image margin
width (copying/
scanning)
3 mm for up, bottom, left, and right
Document
Size (width) 153 to 965.2 mm (38 inches)
Size (length) 153 to 2438.4 mm
Thickness 0.05 to 1.3 mm
Eject direction Forward/backward (switchable)
Optical resolution 600dpi
Scanning method Contact image sensor
Secondary scan-
ning method
Document movement (sheet
pass-through) method
Scan resolution 200, 300, 360, 400, 600dpi
Scan file format JPEG, PDF
Copy resolution
Reading 300dpi
Writing 360dpi
Copy scaling 25 to 400%
Number of contin-
uous copies
1 to 99 sheets
Sensor CIS
Light source Dual LED (RGB)
Rated voltage 100-240V
Rated frequency 50 to 60
Rated current 2.5A
MFP Scanner specifications
Power consumption
In use Approximately 50 W
Ready mode Approximately 25 W
Sleep mode/
power off
0.5 W or less
* The actual width becomes smaller by the size of the “Image
margin width”.
Standards and Approvals
SC-T7200D Series/SC-T5200D Series
Safety UL 60950-1
CSA C22.2 No.60950-1
Low Voltage
Directive 2006/95/
EC
EN 60950-1
EMC FCC part 15 subpart B Class A
CAN/CSA-CEI/IEC CISPR 22 Class A
AS/NZS CISPR 22 Class A
EMC Directive
2004/108/EC
EN 55022 Class A
EN 55024
EN 61000-3-2
EN 61000-3-3
!
Warning:
This is a class A product. In a domestic
environment this product may cause radio
interference in which case the user may be required
to take adequate measures.
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series
Safety UL 60950-1
CAN/CSA C22.2 No.60950-1
Low Voltage
Directive 2006/95/
EC
EN 60950-1
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Appendix
213
