Note:
To remove paper that was loaded but not used, press the
( button and select Remove Paper.
Buttons that are used in the following settings
A
Confirm that Paper Eject is displayed in the
control panel.
Keeping a hand on the cut sheets to prevent them
falling from the printer, press the Z button.
B
The paper will be fully ejected from the printer
and can then be removed by hand.
Loading and Removing
Poster Board
This section describes how to load and remove poster
board from 0.8 to 1.5mm thick.
The printer can be used with board of the following
sizes.
A2/A1/B2/B1
*
/B1 landscape
*
/24 × 30 inch/30 × 40
inch
*
* Not supported by the SC-T3200 Series.
Loading Poster Board
Poster board requires space both behind and in front of
the printer. The approximate amount of space required
is shown below. If the printer is set up near a wall, make
sure there is enough space at the rear.
Paper Size Front (a) Back (b)
A2 444 mm 135 mm
A1 691 mm 382 mm
24 × 30 inch 612 mm 303 mm
30 × 40 inch 866 mm 557 mm
c
Important:
Insert the paper just before printing. The roller may
leave an impression on paper that is left in the
printer.
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Basic Operations
39
