Epson STYLUS Stylus 400 - Bit Image

Bit image
ASCII
ESC * nn
Dec.
Hex.
Description
42 2A
Select Bit Image
ESC * m nl n2
n=nl+tix256
n: Total columns
Total data = (nl x256) xt
t = Number of data bytes per column
Graphics
Horizontal
Vertical
Adjacent
m derittty (dpl) density (dpi)
Pins
dots print t
0
60
60 8
Yes 1
1
120
60 8
Yes 1
2
120
60 8
No
1
3
240
60 8
No
1
4
80
60 8
Ye5
1
6
90
60 24
Yes 1
32
60
180 24
Ye5 3
33
120
180 24
Yes
3
38
90
180 24
Yes
3
39
180
180 24
Yes
3
40
360
180 24
No 3
71
180
360 48
Yes
6
72
360
360 48
No 6
73
360
360 48
Yes
6
ASCII
ESC(Gnn
Dec. Hex.
Description
40 71 28 47
Select Graphics Mode
ESC(GlOn
n=lor49
* Cancel Graphics mode with ESC @
Appendix A-21
