20 | Installing ink
5. Install each ink cartridges in the slot that corresponds to the cartridge.
Hold each cartridge with the arrow pointing toward the printer, then insert it into its slot until it clicks
into place. Make sure you insert each cartridge all the way into the correct slot.
Left ink bay Right ink bay
Slot no. Cartridge Slot no. Cartridge
1 Vivid Light Magenta (VLM) 6 Photo Black (PK)
2 Cyan (C) 7 Matte Black (MK)
3 Gray (GY) 8 Dark Gray (DGY)
4 Light Gray (LGY) 9 Yellow (Y)
5 Light Cyan (LC) 10 Vivid Magenta (VM)
