Epson TM L90 Manufacturing Guide

Confidential
TITLE
SHEET
REVISION
NO.
NEXT SHEET
A
13 12
TM-L90
Roll Paper
Manufacturing Guide
4. CONTINUOUS LABEL ROLL PAPER
4.1 Continuous Label Paper
Continuous label paper is label roll paper without labels die cut in predefined sizes.
Feature: Label size (length) is variable with an autocutter; therefore, it is possible to print labels of
various sizes.
4.2 Specified Original Paper
The specified original paper is the same as that for die-cut label paper.
Print density adjustment and paper for high speed use are also the same as those for the die-cut
label paper.
4.3 Requirements for Thickness and Adhesive Agent
Requirements are as follows:
• Total amount of thickness of the thermal paper and backing paper: 145 µm or less (without
adhesive agent).
• Adhesive agent: Acrylic emulsion
NOTE: When cutting continuous label paper with an autocutter, the autocutter might not
function correctly, depending on the adhesive agent used; therefore, be sure to use
original label paper of the acrylic emulsion type.
Adhesive agents that must not be used are as follows:
•
Acrylic solvent type
•
Rubber type
•
Silicon type
•
Other special adhesive agents
If an original paper other than that specified is used, be sure to confirm the
specifications of the original paper.

Epson TM L90 Specifications

General

Maximum resolution	203 x 203 DPI
Maximum roll diameter	90 mm
Supported paper width	37.5, 79 mm
RS-232 ports	1
Standard interfaces	RS-232
Connectivity technology	Wired
Country of origin	China
Dimensions (WxDxH)	140 x 203 x 148 mm
Flash memory	0.384 MB
Operating temperature (T-T)	5 - 45 °C
Pallet width	800 mm
Pallet height	2600 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2560 g
Quantity per pack	1 pc(s)
