TM-L90
Roll Paper
Manufacturing Guide
1. REQUIREMENTS FOR ROLL PAPER
This printer can use receipt roll paper and label roll paper with the following roll paper
specifications:
Paper type Thermal paper
•
Receipt paper
•
Die-cut label paper
•
Continuous label paper
Form Roll paper
Paper width (backing
paper width)
•
79.5 ± 0.5 mm {3.13 ± 0.02"}
•
37.5 ± 0.5 mm ~ 69.5 ± 0.5 mm
{1.48 ± 0.02 ~ 2.74 ± 0.02"}
Take-up roll paper width
•
80 +0.5/–1.0 mm {3.15 + 0.02/-0.04"}
•
38 ~ 70 mm +0.5/–1.0 mm {1.5 ~ 2.76 +0.02/-0.04"}
Roll paper spool
diameter (inside)
25.4 mm {1"} or more (*)
Roll direction Printed side must face outside.
Be sure that roll paper does not have any cuts or tears at
any place in the roll.
Roll end position Paper must not be pasted to the roll paper spool.
Outside diameter Outside roll paper diameter: Maximum 90 mm {3.54"}
(*) Using roll paper with an inside diameter of 25.4 mm {1"} or less may decrease the
detection accuracy of the roll paper near-end sensor.

Epson TM L90 Specifications

General

Maximum resolution	203 x 203 DPI
Maximum roll diameter	90 mm
Supported paper width	37.5, 79 mm
RS-232 ports	1
Standard interfaces	RS-232
Connectivity technology	Wired
Country of origin	China
Dimensions (WxDxH)	140 x 203 x 148 mm
Flash memory	0.384 MB
Operating temperature (T-T)	5 - 45 °C
Pallet width	800 mm
Pallet height	2600 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2560 g
Quantity per pack	1 pc(s)
