87
Chapter 5 Handling
Removing the Printer Covers
Follow the steps below to remove the printer covers.
When Ejecting Paper Upward
1
Remove the cable slot cover.
2
Put your fingers on the rear cover as shown and then remove it.
3
Put your fingers on the bottom cover as shown and then remove it.
To Next Page
