Epson TM-T20II

33
Chapter 3 Using the Printer Driver
3
4
Changethesizeofthelogoimage.Thesizecanbechangedbydraggingtheknobsonthe
fourcornersofthelogoimageinthepreviewscreen.
5
Editthelogoimage.
6
Aftereditingthelogoimage,clickthe[Register]buttontosavethelogo.
Clickthe[TestPrintRegisteredLogo]buttontotest‐printtheregisteredlogo.Clickthe[Unregister]buttonto
canceltheregistrationofthelogo.
7
Whensettingalogoinmultiplepositions,repeatsteps2to6.
Setting Description
Layout Specifies [Left], [Center], or [Right] for the logo position.
Rotate by 180
Degrees
When this is selected, the logo is rotated 180 degrees. Only the
image is rotated, the logo insertion position does not change.
Grayscale Specifies the grayscale setting. Selects [Multi-tone] or
[Monochrome].
Paper width Sets the paper width. Select [80 mm] or [58 mm] as appropriate
for the printer paper size.
Brightness Moves the slide bar to set the brightness.
