TM-U590/TM-U590P Specifications
*1: Be sure to use a safety-standards-applied power source that meets the following specifications.
Rated output: 24 V/2.0 - 10.0 A, Maximum output: 240 VA or less
Printing method Serial impact dot matrix, 9-pin vertical line, wire pitch 0.353 mm
Printing direction Bidirectional, minimum distance printing
Characters per line
(default)
9 × 9 font: 66; 7 × 9 font: 88: 5 × 9 font; 66
Character structure Font A: 9 × 9, 3-dot spacing (half dots)
Font B: 7 × 9, 2-dot spacing (half dots)
Font C: 5 × 9, 1-dot spacing (normal dots)
Character size Font A: (9 × 9) 1.6 × 3.1 mm
Font B: (7 × 9) 1.3 × 3.1 mm
Font C: (5 × 9) 1.6 × 3.1 mm
Number of characters Alphanumeric characters: 95; International characters: 32;
Extended graphics: 128 × 10 (with one space page)
Print speed Font A: (9 × 9) = 233 characters/second
Font B: (7 × 9) = 311 characters/second
Font C: (5 × 9) = 233 characters/second
Paper feed speed Approximately 60.3 ms/line, 4.23 mm feed; 86.4 mm/s (continuous feeding)
Line spacing (default) 4.23 mm
Paper specifications Paper types: Normal, carbon-copy, and pressure-sensitive
Paper sizes: 70 × 70 mm to 210 × 297 mm
Paper thickness Single-ply: 0.09 to 0.2 mm
Copy paper: Maximum 5 sheets (original + 4 copies)
Backing paper: 0.06 to 0.15 mm
Copy and original: 0.04 to 0.07 mm
Carbon paper: Approximately 0.035 mm
Total thickness: 0.30 mm or less (for any combination from a single original to an
original + 3 copies); 0.36 mm or less (for any combination from a single original to
an original + 4 copies)
Pressure-sensitive paper: Maximum 5 sheets (original + 4 copies)
Backing paper: 0.06 to 0.15 mm}
Copy and original: 0.06 to 0.075 mm
Total thickness: 0.24 mm or less (original to original + 3 copies);
0.30 mm or less (original + 4 copies)
Number of copies Original + 4 copies at 20 to 45°C
Original + 1 to 3 copies at 5 to 45°C
Ribbon cassettes ERC-31
Interfaces (compatible) RS-232 serial or IEEE 1284 parallel, RS-485 (dealer option)
Receive buffer 69 bytes or 4 KB
DKD function 2 drives
Power supply
*1
DC+24 V ±10%
Current consumption
(at 24V)
Operating: Mean: Approximately 1.9 A Peak: Approximately 8 A
Standby: Mean: Approximately 0.3 A
MTBF 180,000 hours
MCBF 29 million lines
Temperature Operating: 5 to 45°C
Storage: –10 to 50°C, except paper
Humidity Operating: 10 to 90% RH
Storage: 10 to 90% RH, except paper
Overall dimensions 185 × 252 × 266 (including a document table) mm (H × W × D)
Weight (mass) Approximately 5 kg

Epson TM-U590 Specifications

General

Color	No
Maximum number of copies	4 copies
Maximum print size	A4 (210 x 297 mm)
Media thickness	0.09 - 0.36 mm
Dimensions (WxDxH)	252 x 266 x 185 mm
Power requirements	24 DVC± 10%
Connectivity technology	Wired
Safety	UL / C-UL / TUV
Certification	VCC # 1, FCC class A, CE
Country of origin	China
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2600 mm
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	56 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	8 pc(s)
Package depth	333 mm
Package width	322 mm
Package height	253 mm
Package weight	5725 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	266 mm
Width	252 mm
Height	185 mm
