Disassembly/Reassembly Overview 27
Epson WF-7620/7610/7110 Series Revision B
Relay Board Holder 17:26 --- 17:26
Waste Ink Tray Holder 17:31 --- 17:31
APG Unit Support Plate 15:11 --- 15:11
APG Driven Shaft 19:23 --- 19:23
Paper Guide Upper Assy
21:22 8:15 29:37
CR Scale
15:37 --- 15:37
CR Driven Pulley Assy 16:31 1:00 17:31
APG Driven Shaft Support Plate 16:32 --- 16:32
PE Sensor 23:53 --- 23:53
CR Guide Frame Assy (w/CR Unit) 27:41 16:24 44:05
Front Frame 29:03 7:45 36:48
PG Adjustment Cam Right 28:13 5:40 33:53
CR Scale Support Plate 28:09 --- 28:09
PG Adjustment Cam Left 28:43 5:40 34:23
Star Wheel Assy
30:45 1:37 32:22
Frame Base 2nd Assy
40:07 4:02 44:09
ASF Motor Assy 41:21 0:35 41:56
Spur Gear 16 41:25 --- 41:25
Pickup Assy 2nd 43:09 --- 43:09
Paper Stopper Assy 1st 40:57 --- 40:57
One Way Clutch Gear 33:21 --- 33:21
Main Board Unit
41:18 19:37 60:55
PF Motor 42:15 0:26 42:41
CR Motor 41:53 0:41 42:34
PE Lever 45:59 0:38 46:37
Paper Guide Middle 46:16 --- 46:16
PE Sensor 46:31 0:38 47:09
Paper Guide Lower Porous Pad
41:23 0:13 41:36
APG Unit 42:04 --- 42:04
Table 2-1. Standard Operation Time for servicing the product
Parts/Unit
Time
Replacement
Adjustment/
Inspection
Total

Epson WF-7110 Series Specifications

General

Print Technology	Inkjet
Max Print Resolution	4800 x 2400 dpi
Duplex Printing	Yes
Input Tray Capacity	250 sheets
Wireless	Yes
Functions	Print
Maximum Resolution	4800 x 2400 dpi
Max Print Size	13" x 19"
Connectivity	USB, Ethernet, Wi-Fi
Paper Sizes	Letter, Legal, A4, A5, A6
Mobile Printing	Epson Connect, Apple AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Print Speed (Black)	15 ppm (ISO)
