Mechanical
Dimensions Height: 324 mm (12.8 in.)
Width: 393 mm (15.5 in.)
Depth: 426 mm (16.8 in.)
Weight Approx. 14 kg (about 30.9 lb)
(Excluding consumables and options)
Electrical
110-127 V 220-240 V
Rated voltage 110 V-127 V 220 V-240 V
Rated frequency 50 Hz/60 Hz 50 Hz/60 Hz
Rated current 11.0 A 6 A
Power consumption During
printing
Average 466 W 454 W
MAX 900 W 960 W
During ready mode 44 W 52 W
During sleep mode
*
2.73 W 2.80 W
During deep sleep mode 0.99 W 1.02 W
During power off mode 0 W 0 W
*
Values represent power consumption while all operations are completely suspended. Power consumption varies
depending on operating conditions.
Note for users in Taiwan:
Rated voltage of the printer in Taiwan is 110 V to 127V.
Standard and approvals
European model:
Low Voltage Directive 2006/95/EC EN 60950-1
EN 60825-1
AL-M300/AL-M400 Series User's Guide
Technical Specifications (AL-M400 Series) 209
