Printer Basics

Part Names and Functions

Control panel Operates the printer.

You can change the angle of the control panel.

Paper cassette 1 or Paper cassette (C1) Loads paper.

Paper cassette 2 (C2) Optional paper cassette unit.

Loads paper.
