www.prolight.co.uk DJ Booth White LED Starcloth User Manual
4
Technical specications
Fitting instructions:
ThisclothisdesignedtobettedtotheEquinoxDJBooth.
Fittheclothfromoneuppercornerrstbyhangingthesewninpocketsontothebooth.
Carefullyunfoldtheclothandattachtheoppositecorner,againbythesewninpocket.
Onceattached,theclothmustbetensionedbytheintegralvelcrostraps.
ESC ENTER UP DOWN
WHITE STARCLOTH
CONTROLLER
www.prolight.co.uk
OUTPUT TO
STARCLOTHDMX INDMX OUTMICFUNCTION
PUSH
ON
OFF
POWER SUPPLY: 100-250V~50/60Hz
FUSE: T1A 250V
01-LEDdisplay
02-Escbutton
03-Enterbutton
04-Upbutton
05-Downbutton
06-Signalindicator
07-Powerindicator
08-Powerinsocket
09-FuseT1A250V
10-Earthpoint
11-On/offswitch
12-Functionknob*
13-Microphone
14-DMXout
15-DMXin
16-Outputtostarcloth
Inthebox:
1 x starcloth,
1 x power cable,
1 x controller &
1 x user manual
ESC ENTER UP DOWN
WHITE STARCLOTH
CONTROLLER
www.prolight.co.uk
OUTPUT TO
STARCLOTHDMX INDMX OUTMICFUNCTION
PUSH
ON
OFF
POWER SUPPLY: 100-250V~50/60Hz
FUSE: T1A 250V
www.prolight.co.uk
ON
OFF
POWER SUPPLY: 100-250V~50/60Hz
FUSE: T1A 250V
02
08 10 11 12 13 14 15 1609
0403
05
06
07
01
*Rotatetoscrollthroughmenu.Presstoenterorpressandholdtoexit.
