Operating instructions
Software version:
Toviewthesoftwareversionofthecontrollerusethe “UP/DOWN”buttonsonthefrontoftheunitto
show“VEr ”ontheLEDdisplay.Nowpressthe“ENTER”buttonandtheversionwillbedisplayedin
theformat“V---”.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.
Static mode:
Toaccessthestaticmode,pressthe“UP/DOWN”buttonsonthefrontoftheunittoshow
“StAt”ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttons
tosetthestaticmodeyourequirebetween“S000-S015”.









Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.
Channel Value Function
1 0-20 LEDgroup1blackout
21-230 LEDgroup1ashspeed
231-255 LEDgroup1fullon
2 0-20 LEDgroup2blackout
21-230 LEDgroup2ashspeed
231-255 LEDgroup2fullon
3 0-20 LEDgroup3blackout
21-230 LEDgroup3ashspeed
231-255 LEDgroup3fullon
4 0-20 LEDgroup4blackout
21-230 LEDgroup4ashspeed
231-255 LEDgroup4fullon
5 0-100 Allchannelsashatspeedsetabove
101-255 Allchannelsfullon
S000 Blackout
S001 LEDgroup1on
S002 LEDgroup2on
S003 LEDgroup3on
S004 LEDgroup4on
S005 LEDgroup1&2on
S006 LEDgroup1&3on
S007 LEDgroup1&4on
5 channel mode:
S008 LEDgroup2&3on
S009 LEDgroup2&4on
S010 LEDgroup3&4on
S011 LEDgroup1,2&3on
S012 LEDgroup1,2&4on
S013 LEDgroup1,3&4on
S014 LEDgroup2,3&4on
S015 AllLEDson
