20
TECHNICAL SPECIFICATIONS
1. Plunge lock button
2. ON/OFF switch
3. Main handle
4. Rear bevel lock knob
5. Rear parallel guide
fixing screw
6. Base plate
7. Rear fine adjustment
knob
8. Anti-kickback knob
9. Track lock
10. Front fine
adjustment knob
11. Front parallel guide
fixing screw
12. Front bevel lock
knob
13. Bevel scale
14. Depth adjustment
knob
15. Track compensation
16. Depth scale
17. Auxiliary handle
18. Mode selector
19. Carbon brush cap
(2x)
20. Slot for track
21. Slot for Parallel Guide
22. Cutting width
indicators
23. Saw blade
24. Dust extraction
outlet
25. Shaft lock
26. 5mm hex key
27. 700mm track x2
28. 3mm hex key
29. Connection adapter
30. Parallel Guide
31. Dust collection bag
32. W
33. Speed regulator
ork clamps x2
Rated input: 220-240V~50Hz
Rated power: 1400W
No load speed: 2000-5000/min
Mitre setting: 0°- 48°
Saw blade dimensions: Ø185x2.2x20mm
Max. cutting depth with track: 62mm at 90°
Max. cutting depth without track: 67mm at 90°
Max. cutting depth with track: 44mm at 45°
Max. cutting depth without track: 47mm at 45°
Protecting rating: IPX0
Protecting class: II
Net weight: 5.4 kg
NOISE DATA & VIBRATION LEVEL
• Noise pressure level (L
): 97 dB(A) (K : 3 dB )
• Sound power level (L ): 108 dB(A) (K : 3dB)
• Hand-Arm-Vibration hand grip: 4.8m/s
2
(K= 1.5m/s )
2
Product description
01
PA PA
WA WA
