INTENDED USE
The Plunge Saw is intended to cut wood and similar materials, gypsum and
cement-bonded fibre materials and plastics. With compatible special saw blades
(not provided) the Plunge Saw can also be used to cut aluminium.
The Punge Saw is only to be used with a specifically designed track. Installation
in a different or homemade track or workbench can cause serious accidents.
Use
OPERATION
Operation of the Plunge Saw without track
• Before each use check the proper function of all installation fixtures of the Plunge
Saw and only use the saw if everything works properly.
• Attach the work piece in such way that it cannot move or bend during work. (H)
Line the work piece respectively.
MODE SELECTION
The mode selector barrel enables fast and easy setting of the major functions
simply by rotating the mode selector (18) to the required mode of operation. (I)
Correct working with the Plunge Saw
• Always hold the Plunge Saw with both hands at the main handle (3) and auxiliary
handle (17).
• Always guide the Plunge Saw forward. Never draw the Plunge Saw back!
• Place the Plunge Saw with the front part of the base plate (6) on the work piece.
Guide the Plunge Saw only against the work piece during operation.
• With the correct forward speed, you prevent overheating of the saw blade, and
melting when cutting plastics.
Dust extraction
The saw is fitted with a 38mm dia. dust extraction outlet (24) suitable for use with
a dust collection bag (31) or for connection to a vacuum system.
See the section ‘Dust Collection Bag’ for details of the dust collection bag.
Blade change
Free plunge, for general cutting
Scribe, for a scribe cut of 2.5mm
Put the connection adapter (29) onto the dust extraction outlet (24) and adjust it
to a suitable position to avoid the wood chips or dust being directed at the body( J).
