28
MARKED CUTTING
ot refeR( (K ) . noitcnuf tuc dekram ot )81( rotceles edom eht nruT.1
"Mode selection" section)
2. Press the plunge lock button (1) and push the motor down. The casing
stops in 2.5 mm cutting depth position.
Note : The markingline shouldbe alignedwith cutting
line A 0 mark. (Refer to “Determine cutting line” section).
SETTING SCRIBE MODE
Scribe mode locks the depth of cut at 2.5mm. An initial scribe cut helps to
prevent friction on the blade, particularly when deep plunge cuts are required.
It is also useful for the initial cut on veneered or melamine laminates.
• Rotate the mode selector (18) to scribe position . (Refer to “Mode
selection” section)
• The plunge depth is now locked so that the blade cannot be plunged deeper
than 2.5mm.
STRAIGHT CUT (90°CUT)
1. Loosen the front and rear bevel lock knobs (4 and 12) and swivel the saw
to 0 ° position on the scale. Tighten the bevel lock knobs again. (Refer to
“Set cutting angle” section)
2. Rotate the mode selector (18) to free plunge position or scribe mode
for a scribe cut. (Refer to “Mode selection” section)
3. Set the desired plunge depth. Ensure that the track compensation (15) is
up when using the saw without track. (Refer to “Set cutting depth” section)
Note : Check the adapter connects firmly before using
the vacuum cleaner.
