4. To switch on the saw press the plunge lock button (1) and the ON/OFF switch
(2) and push the motor down. Guide the saw forward to cut.
5. After completing the cut, release the ON/OFF switch and allow the blade to
come to a complete stop before removing the saw from the work piece.
BEVEL CUT (UP TO 48°) (M)
1. First loosen the front and rear bevel lock knobs (4 and 12) and swivel
the Plunge Saw to the desired graduation. Tighten both bevel lock knobs again.
(Refer to “Set cutting angle” section)
2. Set the desired plunge depth. Ensure that the guide rail track compensation
(15) is in up position when using the saw without track. (Refer to “Set cutting
depth” section)
3. To switch the saw on refer to previous comment (1) and the ON/OFF switch
(2). Allow the blade to reach full speed, plunge the blade to your set depth. Guide
the saw forward to cut.
4. After completing the cut, release the ON/OFF switch and allow the blade to
come to a complete stop before removing the saw from the workpiece.
Note : When operating the Plunge Saw at 90 degs, the
minimum distance between the tool and wall or
workpiece perpendicular plane is 16mm. (L )
Note : The cutting width indicators (22) show the cutting
path for 90° and 45° bevel cuts.
Operation of the Plunge Saw with track
TRACK LOCK
1. Rotate the track lock (9) to the ‘0’ position (before you place the saw in the
track).
2. Place the saw in the track.
3. Rotate the track lock (9) to the ‘I’ position to lock the saw in the track. (N)
Note : The track lock is required when performing bevel
cuts. Set track lock (9) to the “I” position to lock and “0”
position to unlock.
