USING OTHER OPTIONAL ACCESSORIES
WORK CLAMPS
Work clamps are ideal for clamping track quickly and securely to the workpiece
for fast, accurate cutting.
1. Place the track on the workpiece and align it along the cutting line.
2. Thread the thin top arm of one clamp into the lower clamp channel (running
along the underside of the track).
3. Squeeze the clamp handle to raise and secure the grip to the underside of the
workpiece.(T2; T3)
4. Repeat the procedure at the other end
5. Depress the lock button (a) to release the clamp and remove it from the
workpiece. (T4;T5)
of the track. (T1; T2; T3)
Note : Clamp can also be inserted into the upper clamp
channel (on the face of the track).
PARALLEL GUIDE (U1; U2; U3)
• In certain circumstances, it may not be possible to use the track. In such cases
the saw can be used with the Parallel Cutting Guide. This enables accurate cuts
parallel to the edge of the workpiece without use of the track.
• The parallel cutting guide can be used on the left or the right of the blade.
1. Loosen the front and rear parallel guide fixing screws (5 and 11) on the saw.
2. Slide the parallel guide into the mounting slots in the saw base plate.
3. Use a ruler to set the distance from the blade to achieve the required width of
the cut.
4. Re-tighten both the parallel guide fixing screws to secure the parallel
guide in position.
DUST COLLECTION BAG
• For a cleaner, safer working environment, the dust collection bag is designed
for use with the Plunge Saw.
• This dust collection bag has a 1000ml capacity and will collect the majority of
the dust from the cut.
• The non-woven material ensures a high filtering capacity and a vision panel
makes it is easy to see when the bag needs emptying.
• For optimum efficiency, do not allow the bag to become more than ¾ full
before emptying.
• The dust collection bag connects with the connection adapter and simply
push-fits onto the dust extraction outlet (24). (V)
33
