Note : When making bevel cuts it is essential to lock the
saw in the track. For a bevel cut, lock the saw to the
track by rotating the track lock (9) to the ‘I’ position and
set the anti-kickback knob (8) to the ‘I’ position.
1. Check that the track lock (9) and anti-kickback knob (8) are in the ‘0’
position.
2. Engage the saw in the track.
3. Rotate the track lock (9) in to the ‘I’ position.
4. Loosen the front and rear bevel lock knobs (4 and 12) and swivel the Plunge
Saw to the desired graduation. Tighten the both bevel lock knobs again. (Refer
to “Set cutting angle” section)
5. Rotate the mode selector (18) to free plunge position or scribe mode for a
scribe cut. (Refer to “Mode selection” section)
6. Set the desired plunge depth. Ensure that the guide rail track compensation
(15) is in down position when using the saw with track. (Refer to “Set cutting
depth” section)
7. To switch the saw on press the refer to previous comment (1) and the ON/
OFF switch (2). Allow the blade to reach full speed, plunge the blade to your
set depth. Guide the saw forward to cut.
8. After completing the cut, release the ON/OFF switch and allow the blade to
come to a complete stop before removing the saw from the track.
Note : To prevent the saw from kicking back during
plunge cuts follow these steps: Hold the Plunge Saw in
both hands and slowly lower the saw blade. The
cutting width indicators (19) show the foremost and
rearmost cutting points of the saw blade (Ø 185mm) at
maximum cutting depth and when using the track.
WITH THE TRACK (0-48˚) (S)
