31
The anti-kickback knob (8) is designed to prevent operator injuries due to
kickback. The anti-kickback knob (8) counteracts the movement if you try to
guide the Plunge Saw on the guide rail back or if the saw kicks back, e.g. due
to the saw blade jamming.
Rotate the anti-kickback knob (8) to the ‘0’ position (before you place the saw
in the track). (O)
USING THE FINE ADJUSTMENT KNOBS
The fine adjustment knobs (7 and 10) enable you to remove excessive play
between the track and the saw to ensure cutting accuracy as the saw moves
along the track.
• Loosen the knobs securing the front and rear fine adjustment knobs (7 and
10). (Q)
• Place the saw in the track.
• Adjust the cam levers (A) that they remove excessive play, then re-tighten the
fine adjustment knobs to secure the cam levers (A) in position.
Note : When you slide the saw onto the guide rail of the
track, the anti - kickback feature is automatically
engaged. (P)
Note : If kickback does occur, check that the track is not
damaged before continuing with the cut.
Note : The cams (B) are fully engaged when the cam
levers (A) are at the rear of their slots. (R)
ANTI-KICKBACK
