SET CUTTING ANGLE
The Plunge Saw can be angled between 0° and 48°. (C)
1. Loosen the front and rear bevel lock knobs (4 and 12).
2. Pivot the body of the saw until the bevel angle pointer adjacent to the front
bevel lock aligns with the bevel angle required on the bevel scale (13).
3. Tighten the bevel lock knobs firmly.
4. The saw is now secured ready for cutting at the bevel angle required.
PREPARING THE TRACK
Note : When accuracy is critical, use a set square (not
provided) to check the angle and make test cuts on a
scrap piece of material.
Note : There are two piece protective sleeves on both
noitamrofed kcart diova hcihw kcart hcae fo sdne lanimret
and damage during transportation. Remove the
protective sleeves from both ends of the track before
using the track. (D1)
Note : Before first use and from time to time as needed,
apply a light spray of lubricant so that the saw will glide
smoothly along the length of the track. Do not allow
dust, shavings or other debris to build up on the track.
TRACK PACK(D1)
The track pack includes:
• 1 x track bag
• 2 x 700mm lengths of track for optimum performance of the Plunge Saw
• 2 x track connectors (Note: each connector consists of two parts)
• 1 x 3mm hex key
Note : Maximum cutting depth for working without track
can reach 67mm in special case if the track
compensation lever is set in “down” position. The real
cutting depth is then 5mm more than the indicated
value on the scale. This setting shall only be applied if
the ordinary maximum cutting depth for working
without track (62mm) is insufficient.
