36
Note : The rotation direction arrows of saw blade and
saw must be aligned.
8. Replace the outer flange in such a way that the slaving pins sit in the
recesses of the inner flange.
9. Press and hold the shaft lock and tighten the screw. Press the plunge lock
button(1) for the casing to swivel up again.
Note : The carbon brushes must be replaced by a pair of
similar carbon brush available through the after-sales
service organization or qualified professional person.
If the power cord is damaged, it must be replaced by the manufacturer,
The saw is equipped with self-isolating special brushes. They are automatically
isolated when worn, and the tool stops.
Check the carbon brushes regularly. Replace the carbon brushes with genuine
spare parts if either brush is worn to less than 6mm long.
its service agent or similarly qualified person in order to a safety hazard.
BRUSH REPLACEMENT (W4)
POWER CORD
