Erbauer ERF298MSW - Mitre Saw Overview; Component Identification (Fig 1)

RH OVERVIEW OF MITRE SAW
Fig 1
1. SLIDE CARRIAGE LOCK KNOB
2. SAFETY HEAD RELEASE LEVER
3. POSITIVE STOP LOCKING LEVER
4. MITRE LOCK HANDLE
5. MITRE LOCK HANDWHEEL
6. SAW HEAD LOCK PIN
7. DEPTH GAUGE
8. BATTERY
6
1
3
2
4
7
8
5
