3 • Controls
80116-276_V24169
2022-01
Controls at the rear
Fig. 3-3
1
2
ECB ECB
2
1
Ar
1
2
3
4
5
1 Purge pin
2 Argongas connector
3 Pressure sensor terminal
4 ECB sockets (Erbe Communication Bus)
5 Potential equalization terminal
