Test procedure
1. Plug the MF connector of the APC handpiece (20132-043) into the
test specimen.
2. Press the CUT button on the APC handpiece. The test program must
confirm activation by lighting up the relevant field in color in the
"Handpiece" icon.
3. Press COAG button on the APC handpiece. The test program must
confirm activation by lighting up the relevant field in color inn the
"Handpiece" icon.
4. Remove the APC handpiece.
1. Plug the MF connector of the VIO APC handpiece (20132-200) into
the test specimen.
2. Press the CUT button on the VIO APC handpiece. The test program
must confirm activation by lighting up the relevant field in color in the
"Handpiece" icon.
3. Press COAG button on the VIO APC handpiece. The test program must
confirm activation by lighting up the relevant field in color inn the
"Handpiece" icon.
4. Press ReMode button on the VIO APC handpiece. The test program
must confirm switchover by lighting up the relevant field in color in
the "Handpiece" icon.
5. Remove the VIO APC Handgriff.
Test on APC and FiAPC sockets
(Activation FORCED APC)
Test setup
• The test specimen is connected to the power supply via a VIO D HF
surgical unit.
• The argon gas bottle is connected to the test specimen.
• The NE socket of the VIO D is connected to one face of a metal panel.
On the metal panel there is a viscose sponge soaked with a 0.9 %
saline solution.
• With APC socket: The VIO APC handpiece with applicator is plugged
into the test specimen.
• With FiAPC socket: The FiAPC probe is connected to the FiAPC socket.
The dual-pedal footswitch with ReMode is connected to the VIO D.
IMPORTANT! For this test only Erbe pressure reducers may be used. For article num-
bers see chapter "Testing and measuring equipment".
