7. Appendix Technical Specification
Model ERE-E1B ERE-E1C ERE-E1S
Photo and video
Image Sensor
5Mega pixel 1/3 "HD color CMOS image sensor
：
0.005 Lux / F1.2 / 30IRE (LED off)
Effective pixels： 2560×1920 / 4915.2K
Photo Definition
12M/8M//5M/3M/2M/1M
4608×2592/3624X2448/2560×1920/2048×1536/ 1920×1080/1280×720
Shooting No.
1~5
Video Definition：
1920×1080/30 fps；1280×720/60 fps；1280×720/30 fps；
720×480/30 fps
Video length： 1~120s
：
（
；
）
Trigger Time： < 0.8 Sec
：
First photo, then video
Max-Shooting (Per Day) ： Support, 0~255, 0 means no limit.
：
Support thumbnail,16 times enlargement, support video playing, support advanceX2/X4, retreat X2/X4
Display Screen： 2.0 "LCD Screen; definition: 960 × 480; 16.7M color
Audio
Microphone： 60dB High Sensitivity Sound Collection
Loudspeaker
0.5W（8Ω） Hi-Fi Loudspeaker
Audio record： ON/OFF
Boot Sound
ON/OFF
Key Sound： ON/OFF
PIR
PIR Sensing Angle：
Main PIR: 50 °, 8 zone, each zone 10 °
Side PIR: Left and right light beams form an angle of 140 °, left and right of the five zone, each zone 10 °
PIR Sensor Distance
20M (at 25°C)
：
Main PIR / Main PIR & Side PIR / OFF
PIR Sensitivity： Auto / low / normal / high
：
0-59sec，1-59min Programmable
GSM; Support SSL(Security Socket Layer)
Frequency band： No 850/900/1800/1900MHz
GSM Mode： No MMS/GPRS/OFF
MMS Photo Size
No 960x540
Send Number： No 0 to 255,0: No limit
Daily Report： No ON/OFF
Remote Control： No
Night Vision
Light source：
850nm or 940nm
2 / 4ea，IR H-LED
650nm，2ea
white LED
850nm or 940nm
2 / 4ea，IR H-LED
Night Vision Distance： 30M 30M 30M
：
Auto / Day / Night
Light Level： Standard(900mA) / Plus(1300mA)
User Interface Stamp
Shooting date, Moon phase, Camera ID and Temperature are optional: ON / OFF
Security Setting
Support 4 numbers, auto lock the camera if wrongly input the password for 6 times. Padlock installation.
Anti-theft lock hole
Timer
Can set three period of time per day and weekly repetitions. Support automatic interval shooting and timer
triggered shooting
