Operation Manual
Version: 12/01
13
er900L Operation Manual
Art-Nr: 475.043
Ergometer
Type er900L
4 Putting into Operation
Check the mains fuse at the respective workstation prior to putting into operation the
device. Minimal fuse value: 16A.
4.1 Operating elements and Connections
Putting into Operation
1
3
2
54 6
7
8
9
10
11
1 Power connector, fuse and main power switch
2 Couch and seat adjustment
3 Mains power switch
4 Shoulder support
5 Handle with mounting for patient
6 Head support
7 Locking castors
8 Measurement head with keypad, display and printer
9 Blood pressure cuff , connection to the left or right at choice
10 Arm rest for blood pressure measurement
11 leg erst left + right, attachle (optional)
